ULTIMATE LUXURY SPORTFISHING BOAT UNDER 50'

45′ EXPRESSFISH

The new 45′ ExpressFish is the ultimate luxury sportfishing boat under 50′, offering the elegance and style from the popular 42′ ExpressFish on an extended aft cockpit platform.

Powered by twin Volvo IPS650, the 5.5L diesel engines provide an effortless and efficient 30 knot cruise @ .8 NMPG, reaching a top speed of 35 knots. The new hull design ensures a soft and stable ride with a 20° deadrise at the transom, generous chines, and strakes providing an incredibly soft, stable and quiet ride. The yacht features impeccable attention to detail, high-quality all-aluminum construction, and an open ambiance with the large sunroof, bifold glass doors, and fully opening rear windows.

The high speed and extended range 45’EF comes fully equipped to cruise to new destinations previously out of reach, with an extensive navigation electronics package and all the creature comforts you would come to expect in a world class yacht.

SPECIFICATIONS

Structural – 10 year limited
Deck hardware – 1 year limited
Joinery – 1 year limited
Exterior Coatings – 1 year limited
Machinery/Electrical – 1 year limited
Propulsion – As per manufacturer
Electronics – 1 year or as per manufacturer’s warranty

MAIN FEATURES

Two staterooms with one head
Marine aluminum construction
Constructed to ABYC yacht standards
Nida-Core & Italian lite panel cores
7 to 30 knot cruising speeds
35 knots top speed
Extended range capacity
Low sound levels
IPS joystick offers ease of handling
Generous sport fi shing cockpit
Open salon with expansive 360 degree views
Large one-piece curved windshield
Excellent sight lines from lower helm
Spacious master stateroom
Large head with separate shower
Chef’s galley
Yacht interior fi nished in black walnut
Garmin radar/plotter/sounder/autopilot
Automatic fi re suppression system
Fusion stereo with salon & cockpit speakers

Length overall 46′ 6″
Length @ waterline 39′ 6″
Beam – maximum 14′ 2″
Draft 3′ 6″
Height above waterline 14′ 6″
Displacement – fully loaded 35,000 lbs
Displacement – lightly loaded 29,000 lbs
Fuel (diesel) capacity 600 US gal
Fresh water capacity 90 US gal
Black water capacity 38 US gal
Propulsion (2) Volvo IPS 650
Engine (2) Volvo D6-480 (480hp)
Generator Northern Light 9KW
Maximum speed (half load) 35 knots
Cruising speed (half load) 30 knots
Fuel economy @ 30 knots .8 NM per gallon
Best fuel economy @ 27 knots .9 NM per gallon
Range @ 27 knots 540 NM
Range @ 8 knots 1200 NM

Marine aluminum construction
1/4″ 5086-H116 bottom, transom & chine plates
3/16″ 5086-H116 side plates
5/32″ & 3/16″ 5052-H32 deck plates
5/32″ 5052-H32 superstructure
Welding-Pulse Mig & Tig
Hull, deck and cabin foam insulation
Awlgrip® complete fairing & paint system
International Paint® primer & bottom paint system
Prop-Speed® underwater coatings on IPS drives & props

DOWNLOAD SPEC SHEET

COASTAL CRAFTS FOR SALE

REQUEST MORE INFO

SPECIFICATIONS & COMPLETE DETAILS

Fittings all in 316 stainless steel
Bow rail (1.25″ 316-SS)
Weld-on cabin side handrails
Weld-on cabin end grabrails
(9) Gemlux 10″ cleats (pop up stainless steel)
Lewmar Anchor windless (helm & deck switches)
55 lb Ultra® anchor with swivel
100′ chain spliced to 300′ X 5/8″ rope (marked every 50′)
Ultra® anchor roller assembly
Anchor washdown coil
One-piece curved windshield
Fritted side windows (two opening panels – tinted)
Port bulkhead window hinges open (top mount hinge) with electric lift actuator
Double bi-fold rear glass panel door
“Lewmar” port light (rectangular) in rear bulkhead
(2) “Lewmar” deck hatches (20″) in foredeck
Forward anchor locker hatch with washdown

144 square foot cockpit
Mezzanine deck (with rod storage below) with double wide bench seat (insulated cooler beneath)
Starboard side boarding door (opening in and aft)
Port & Starboard transom seats (fold down)
Transom cabinet with tackle storage
(2) Fish boxes (in-deck, insulated) with drains
(2) Tackle lockers (under gunnel)
48″ rear overhang on hardtop
Boarding ladder
Cockpit shower (retractable)
Fresh & sea water washdown outlets
(2) Imtra LED ceiling lights
Low level courtesy lighting
(2) Fusion 8.8″ Speakers

Recessed cabin top (optional with sunroof)
Deck drains
Non-slip deck coatings
Hinges radar mast (mounted aft)

Black walnut joinery
Lite ply used with all veneer panels
Teak plank flooring
“Ocean Air” window blinds mounted in valances with pull down roller blinds on rear door/window
Vinyl with foam wrapped ceiling panels and side wall panels
Helm seat with armrests on S5 suspension base (Volvo joystick mounted)
Helm side console cupholder and induction phone charger
Port side doublewide passenger seating with cupholder and induction phone charger
Port side “U” shaped Settee (seating for 6) with high gloss table on ATEP SS drop pedestal (converts to queen berth)
“Ultra Leather” upholstery
Starboard side galley
Valance accent lighting
(12) Imtra Ventura LED ceiling lights on dimmer
(4) 6″ Fusion ceiling speakers & subwoofer under settee
(3) 110V receptacle outlets
(2) USB chargers
Storage basement under salon floor

Galley lower cabinets (customizable)
(6) galley drawers and (1) cupboard
(5) settee drawers adjacent to galley
Brushed stainless steel flush latches (locking)
Avonite® or Corian® countertops and backsplash
Isotherm® SS fridge/freezer (7.5 cu/ft side by side)
Force 10® cook top stove (3 burner electric)
Built in Z-Line® convection microwave
Stainless steel under mount galley sink
Galley faucet (single lever)
(2) 110V receptacle outlets

Vanity cabinets (lower and upper)
Vanity drawers and mirrored upper cabinet doors
Avonite® or Corian® countertop and backsplash
Porcelain under mounted vanity sink
Vanity faucet (single lever)
Electric toilet (full size)
110V receptacle outlet
Towel bar
Teak plank flooring
(4) Imtra Ventura LED ceiling lights on dimmer
(2) vanity accent lights on dimmer
Head extraction fan

Watertight shower stall with seat
Corian “Wet Walls” with Corian tile floor panels
Wall mounted mixing valves and adjustable shower head
Towel locker (recessed in wall)
Towel bar
Shower curtain on SS bar
(4) Imtra Ventura LED ceiling lights on dimmer
Accent lighting (low level) on dimmer
Shower extraction fan

Teak plank flooring
Island berth (66″ X 78″) with 6″ mattress
Step platforms on either side of berth for easy access
Port & Starboard full height lockers
Port & Starboard dresser cabinets
Port & Starboard side boards with recessed storage pockets alongside berth
Headboard with recessed pocket shelving and pocket for artwork
(4) Drawers under foot of berth
(2) 20″ deck hatches with Ocean Air screen/shade
Soft Touch ceiling panels with foam backing
(3) 110V receptacle outlets
(2) USB chargers
(8) Imtra Ventura LED ceiling lights on dimmer
(2) Imtra reading lights
Accent courtesy lighting (low level) on dimmer

Teak plank flooring
Twin single bunks (fill cushion to convert to queen)
Hanging locker with storage
Opening port light with screen
Stateroom finished in black walnut
Vinyl with foam wrapped ceiling and wall panels
(1) 110V receptacle outlet
(1) USB charger
(6) Imtra Hatteras LED ceiling lights on dimmer
(2) Imtra reading lights
Accent courtesy lighting (low level)

Volvo® tilt steering with Edson® steering wheel
Volvo® dual engine controls
Volvo® key fob ignition panel
Volvo® engine management panel (7″ color)
Volvo® Joystick control (helm seat armrest)
Ritchie® Navigator Compass
(2) Garmin® 8617 displays
Garmin® VHF 200
Garmin GHS 10 VHF remote (VHF 300)
Volvo® autopilot control
Rocker switch panel

(2) Garmin® 8617 displays
Garmin 19X GPS sensor
Garmin® GMR 24 24″ HD radar
Garmin® GSD 25 sounder module
Airmar® 1KW thru hull transducer (200kHz)
Airmar® 1KW thru hull transducer (50kHz)
Volvo® autopilot with joystick steering
(1) Garmin® VHF 200 radio with Morad® antenna
(1) Garmin® VHF 300 radio with Morad® antenna
(2) Garmin® GHS 10 VHF Remote
Garmin® AIS600

Northern Lights® 9KW generator with sound shield
Centek® water-lift & water/gas separator mufflers
(2) Racor® FG900 fuel/water filter (engines)
(1) Racor® FG500 fuel/water filter (generator)
Manual Whale bilge pump
(2) Z4A hull zinc anodes
Soundown® engine room insulation
Air intake and ambient air venting and ducting
Humphree trim system (750mm)
Air horn (dual trumpet)
Imtra windshield wiper & washer system
(4) Rule 2000 GPH bilge pump
(1) Whale manual bilge pump
Fireboy fire suppression (engine & mechanical spaces)
Head & shower vent discharge fan
Hot water heater (electric)

600 USG fuel tank (aluminum) with sender
90 USG domestic water tank (SS) with sender
38 USG black water waste tank (plastic) with sender, discharge pump and plumbing
Techtronic shower sump with discharge pump

Two Volvo® IPS650 (D6-480 diesel engines)
(1) Volvo® engine management panels (7″ color)
(1) Volvo® joystick control
Volvo® dynamic positioning system (DPS)
Volvo® low speed trolling
Volvo® single lever control
Volvo® cruise control
Volvo® spare parts kit

Webasto 25K air conditioning/reverse heat

12V DC house bank & engine start
(5) Battle Born lithium-Ion batteries
(12V@500 AH house bank)
(2) AGM (12V) engine start batteries
(1) Victron Quattro 5 KW inverter (100 Amp charger)
Pro-Sine charger (start bank)
(4) Sterling B2B chargers
240V/50A Shore Power with Glendinning cable reel (with 50′ cord on the reel)
Charles® galvanic isolation transformer
Battery coupling system
Navigation lights (LED)
High water bilge alarms
High temperature alarms in engine room
Domestic freshwater pump
Seawater washdown pump
Imtra LED recessed ceiling lights on dimmers
LED lights in engine & mechanical compartments
Fusion Apollo RA770 stereo head unit with
(2) 150 watt amps
– (4) 6″ Fusion Interior speakers with subwoofer
– (2) 8.8″ Fusion exterior speakers

12V DC house bank & engine start
(5) Battle Born lithium-Ion batteries
(12V@500 AH house bank)
(2) AGM (12V) engine start batteries
(1) Victron Quattro 5 KW inverter
(100 Amp charger)
Pro-Sine charger (start bank)
(4) Sterling B2B chargers
240V/50A Shore Power with Glendinning cable reel (with 50′ cord on the reel)
Charles® galvanic isolation transformer
Battery coupling system
Navigation lights (LED)
High water bilge alarms
High temperature alarms in engine room
Domestic freshwater pump
Seawater washdown pump
Imtra LED recessed ceiling lights on dimmers
LED lights in engine & mechanical compartments
Fusion Apollo RA770 stereo head unit with (2) 150 watt amps
– (4) 6″ Fusion Interior speakers with subwoofer
– (2) 8.8″ Fusion exterior speakers

FACTORY OPTIONS

Port side cockpit helm station (hidden)
– Volvo® joystick
– Volvo® engine start/stop panel
– Volvo® dual engine controls
– Garmin® 8617 display
Upgrade radar to Garmin® GMR xHD3 4′ (12KW) open array
Flir M332 night vision stabilized thermal lens (with radar mast mount)
Flir M364C nigh vision premium stabilized thermal & low light lens (with radar mast mount)
ACR RCL-100 remote searchlight
SeaKeeper 5 gyro stabilizer
Espar D5 AIRTRONIC main heat
Espar D2 AIRTRONIC aux heat (cold weather cruising)
Upgrade to Hurricane hot water heater (diesel – rapid recovery)
Windshield defrost system (engine heat)
Spectra 340C water maker
30 Amp shore power system with Victron house battery charger
(3) Underwater transom lights (multi-color)
Humphree Active Ride (dynamic ride stabilization
(1) Volvo spare prop set

Webasto Sunroof with Ocean Air blind & screen
Salon TV recessed in ceiling on drop down lift
Fwd Stateroom TV (pocketed in wall)
SureShade cockpit awning (recessed in hardtop – automated)
Port side cockpit boarding door
Isotherm refrigerator drawer under mezzanine seat
Steelhead WD800 davit crane with tender cradle (Relocate radar forward)
Flexi-Teak G2 synthetic cockpit decking
Flexi-Teak G2 synthetic cover boards
Teak cover boards
Windshield “exterior” mesh cover (partial sun block – see through)
(6) Fold down cabin side steps (access to upper deck)
Upgrade helm seat to Stidd Admiral 500N
Series Slimline

Gemlux Blue Water outriggers with 18’ poles
Fish cleaning table (custom) mounted on transom
Replace transom tackle cabinet with built-in Live Well (70 gal)
(2) Additional tackle lockers (under gunnel)
(6) Weld-On rod holders mounted (3) per side of the cabin
(2) Scotty power points
(1) Burnewiin GM650 deck mount
(1) Burnewiin RH5710 rod holder
(1) Burnewiin UM6080 adaptors with down rigger plate
(1) Gemlux Screwless Cup/Rod Holder (0, 15 or 30 degree)
(2) Hubble 20A electric reel power points
Pot Puller deck mount and power point

ULTIMATE LUXURY SPORTFISHING BOAT UNDER 50'

45′ EXPRESSFISH

SPECIFICATIONS

MAIN FEATURES

SPECIFICATIONS & COMPLETE DETAILS

FACTORY OPTIONS

COASTAL CRAFT YACHTS

tel: 604-886-3004
email: [email protected]
1038 Venture Way
Gibsons, BC
V0N 1V7 Canada

INFO LINKS

» Models
» For Sale
» News + Events
» Community
» Contact

FOLLOW US

» Facebook
» YouTube
» Instagram

ULTIMATE LUXURY SPORTFISHING BOAT UNDER 50'

45′ EXPRESSFISH

SPECIFICATIONS

MAIN FEATURES

SPECIFICATIONS & COMPLETE DETAILS

FACTORY OPTIONS

COASTAL CRAFT YACHTS

tel: 604-886-3004 email: [email protected] 1038 Venture Way Gibsons, BC V0N 1V7 Canada

INFO LINKS

» Models » For Sale » News + Events » Community » Contact

FOLLOW US

» Facebook » YouTube » Instagram

tel: 604-886-3004
email: [email protected]
1038 Venture Way
Gibsons, BC
V0N 1V7 Canada

» Models
» For Sale
» News + Events
» Community
» Contact

» Facebook
» YouTube
» Instagram
