• The axe bow design with an elongated waterline and wave piercing characteristic enhance the ride quality while reducing the yacht pitch in seas.
• Aluminum yacht construction.
• Volvo® IPS propulsion provides speed & economy.
• Equipped with gyro stabilization.
• The exterior deck layout with aft and forward seating and lounges create generous social and private areas to enjoy with friends and family.
• Walk around deck layout.
• The enclosed cabin with 360o visibility provide protection and comfort from the elements.
• Two staterooms with master suite forward create an exceptional owner experience.
• Transom tender garage fits a Williams Turbojet 285LP tender.
• Large swim platform with centre drop section.

• Length – 54′ 11″
• Waterline Length – 50′ 6″
• Beam – 15′ 10″
• Light Displacement – 51,000 lbs
• Loaded Displacement – 59,000 lbs
• Diesel Fuel Capacity – 600 US gallons
• Fresh Water Capacity – 110 US gallons
• Black Water Capacity – 38 US gallons
• Propulsion – (2) Volvo® IPS950 (D11-725)
• Propeller – Volvo® P5
• Stabilizer – Seakeeper 9
• Tender – Williams Jet Tender 285
• Top Speed (Loaded) – 38 knots
• Cruise Speed (80% Load) – 30 knots
• Fuel Economy @ 80% Load – .6 NMPG
• Range @ 30 knots – 360 NM
• Aluminum Yacht Construction
• ISO Design Category  B

DESIGN & ENGINEERING

• Exterior styling & general arrangement by Coastal Craft Yachts
• Engineering by DLBA Naval Architects
• ISO Category B

CONSTRUCTION

• 100% Marine aluminum welded construction
• 5083 Aluminum plate
• MIG & TIG welding

INSULATION

• “Soundown” Tuffmass acoustic barrier
• Spray foam insulation throughout

EXTERIOR COATINGS

• “Awlgrip” Awlcraft® SE – top coatings
• “Awlgrip” Primers & fairing compound
• “International” underwater primers & antifouling coatings

COCKPIT SUN LOUNGE

• Large rear sun lounger with full width backrest with cup holders

COCKPIT SEATING

• Forward L shaped seat/lounge with table facing aft (drawer fridge under seat)
• Rear L shaped seating with large table facing forward (drawer fridge under seat

FORWARD LOUNGE

• Large forward sun lounge with (2) articulating backrests
• Full walk around decks with low level accent lighting
• Swim platform with hydraulic drop section and exterior shower socket with drop in pole
• Sureshade® – AMS power shade awning provides relief from the direct sun in thecockpit
• Flexiteek® decking on all exterior decks
• Low level lighting accents all exterior social spaces
• Large swim platform with exterior shower

• Tender Garage beneath the aft sun lounge with electric lift actuators
• Williams® turbojet 285lp tender
  – BRP Rotax 90hp engine
  – Quick release wheel
  – Bathing ladder
  – LED deck lights
  – Underwater lights
  – Fusion mp3 music package
• Swim platform (centre section) lowers for swimming & tender launch and retrieval
• Williams® TLS3 tender launch system with retrieval winch
• Tender shore power and wash down provisions inside garage
• Garage lighting

• Recessed cabin top (optional with sunroof)
• Deck drains
• Non-slip deck coatings
• Hinges radar mast (mounted aft)

The main salon features 360o unobstructed views through the elegant one-piece curved windshield, full side windows and rear glass bi-fold door and drop window. The large opening sunroof contributes to converting this enclosed cabin space into the outdoors. The sunroof is equipped with a screen and shade. With headroom inside the salon at 6′ 9″ it. The lighting throughout the main salon is controlled with (3) dimmable zones including forward ceiling, aft ceiling and accent lighting including low, mid level and upper level lighting. There is a drop down 32″ TV recessed in the cabin ceiling. The TV swivels 180o making it viewable from inside the cabin looking aft or from outside in the cockpit looking forward. There are (4) JL® Audio 6.6″ ceiling speakers along with a subwoofer to provide enjoyable listening from inside the salon.

The port side full wrap around settee seats up to five comfortably with a large table to host friends and family for indoor gatherings. The table is mounted to a stainless steel pedestal that drops to make this space into an additional sleeping area with provided cushion. The forward cabinet has drawers incorporated providing generous storage easily accessed from the galley on the opposite side.

The starboard side helm location features a comfortable helm seat elevated to the ideally height for unobstructed 360o visibility. The helm seat incorporates a powered armrest with integrated Joystick control. The armrest when lifted enhances the driver experience creating the most ergonomic docking and driving position possible. Utilizing Volvo® Joystick Docking, Joystick Control (Steering and Shift & Throttle Controls) and Joystick Assisted Docking the operator has full control of the vessel in their right hand. The clean layout of the dash incorporates two 19″ Volvo® Glass Cockpit Displays in the upper panel. The owner panel features a flush New Wire Switch Panel, Volvo® Engine Display Panel, air conditioning vent and VHF handheld radio. On the top side console you’ll find a cup holder forward and Volvo® engine controls. The seat sits atop of the ship’s electrical cabinet. Opening its double doors you find the DC and AC electrical panels for vessels systems.

The double wide co-pilot seat provides excellent visibility underway providing passengers with the opportunity to be part of the journey ahead. The port side console features a cup holder, induction phone charger and air conditioning vent to provide comfort and convenience. The seat sits atop of a cabinet providing a bank of deep drawers that contribute to generous storage spaces onboard this yacht.

The attractive clean lines of the galley with solid surface counter top and backsplash draw guest into the salon area. The accent lighting incorporated the full length along the bottom of the cabinets, in the top of the back splash and upper window valance provide sophistication and ambiance to the space. The lower cabinets offer (2) SubZero® fridge & freezer drawers, convection microwave, electric range and an abundance of drawers and cupboards.

The main stateroom is located forward with a queen size berth with entry steps on either side for easy access. A large dresser cabinet is located beneath the berth with four drawers. There are two additional drawers built in to the step up platform on either side of the berth cabinet. To starboard there is a full height cabinet with an open shelved upper cabinet with mirrored back and accent lighting. The lower section has two drawers and a tip out locker. The port side cabinet has an upper enclosed hanging locker and three large drawers in the lower cabinet. A full height mirror is mounted to the port aft wall with a 32″ TV recessed in the wall on the starboard. Lighting includes (3) dimmable zones as well as (2) reading light mounted over the head of the berth. There is a large skylight with shade located in the ceiling at the foot of the berth and (2) opening port lights (with screens/shades) located on with side of the berth for fresh air. The space has a zone controlled heat & cooling to ensure maximum comfort

Access to the guest stateroom is located aft of the salon settee down a few short steps to reveal a comfortable accommodation space with twin single berths that convert to make a queen berth when desired. The well appointed space features a large full height hanging locker with shelving to neatly stow your guests personal belongings. The 2 zone lighting ensures the ambiance is always comfortable and relaxing.

Located forward below decks to starboard. The head features a lower vanity cabinet and under mount porcelain sink. The full size euro-quiet toilet is located beside the vanity. The upper cabinet features a mirrored front medicine cabinet with inset accent lighting.

Located across the companionway from the Head, the separate shower compartment is a very generous in size with rain-head shower faucet and handheld shower wand with mixing valve.

• Webasto® FCF platinum 25k air conditioning / reverse air heat – main salon / aft stateroom
• Webasto® FCF platinum 10k air conditioning / reverse air heat – fwd accommodation

• (1) 600 USG Diesel fuel tank (integral)
• (2) Primary engine water/fuel filters
• (1) Racor® generator fuel filter

• Shorepower
  – 50 amp – glendinning 100′ cable-master
  – 30 amp – smartplug with 50′ chord
• Victron® Cerbo GX with MFD integration
• 24v Engine start batteries
• 12v (600Ah) Lithium house battery bank
• 12v Generator start battery
• Victron® 5kw quattro inverter/charger (house batteries)
• Victron® Skylla 70amp charger (house batteries)
• Victron® battery charger 30a (engine batteries)
• Pro Mariner® battery charger 50a (engine batteries)

• • Seakeeper® 9 Gyro stabilizer
• Generator
  – Fisher Panda mini 12kw
  – Gas water separator muffler
• Delta-T engine room ventilation
  – With engine auto shutdown
• Fire suppression system
  – Fireboy ES-5000 with Delta-T fire dampener shutdown
• Bilge pumping
  – Engine compartment
  – (3) rule 2000 GPH with manual & auto function
  – Fwd cabin – (1) rule 2000 GPH with manual & auto function
  – High water bilge alarms in all (2) compartments
• Domestic water system
  – 110 USG stainless steel tank
  – Headhunter Mach 5 (230v) water pump
  – Torid IX series 10 USG hot water tank
• Black water system
  – Sealand 38 USG blackwater tank with diaphragm discharge pump
• Grey water system
  – (3) Trionic 4 USG accumulator tank with discharge pump
• Williams® tender launch system

INTERIOR

• Salon (3 dimmable zones)
• Fwd stateroom (3 dimmable zones)
• Head (2 dimmable zones)
• Shower (2 dimmable zones)
• Aft stateroom (2 dimmable zones)
• Mechanical compart

EXTERIOR

Cockpit

• Overhead (1 dimmable zone)
• Perimeter low level lighting (full spectrum) – poco control
• Cabin side low level accent light (full spectrum) – poco control
• JL® Speaker light (full spectrum) – poco control

Bow

• Osculati® “aurora” pop up table lights Underwater
• (4) Lumitec® (full spectrum) – poco control
•  Tender garage (1 zone – remote switched)
• Engine compartment (1 zone – remote switched)

• (2) 19″ Volvo® glass cockpit displays (Garmin® 9019)
• Garmin® GPSMAP 8610 cockpit display (8″)
• Garmin® GMR Fantom 54 (4′ open array)
• Garmin® GSD25 sonar module
• (1) Airmar® SS175HW chirp transducer (1kw)
• (1) Airmar® SS175L chirp transducer (1kw)
• Garmin® GC 14 marine camera (engine room view)
• Garmin® GC 255 flush mount camera (stern view)
• Garmin® VHF 315 marine radio with antenna
• Garmin® AIS 800 blackbox transceiver
• Seaview® radar tower

JL® Media Master MM105 marine stereo

• (14) JL® 8.8 Marine speakers – exterior
• (4) JL® 6.5 Marine speaker & (1) fusion 10 subwoofer – interior
• (2) JL® XDM 800 amp, (2) JL XDM 600 amp,
• (1) JL XDM 700/5 amp
• 32″ TV – salon (noval “ceiling” drop mount)
• 32″ TV – Master stateroom (recessed in wall)
• Starlink® – Mounted on top radar mast

• Fuel (diesel) – (1) 600 USG aluminum tank (integral)
• Fresh water – (1) 110 USG stainless steel tank
• Black water – (1) 38 USG plastic tank
• Hot water – (1) 10 USG stainless steel tank

Twin Volvo® IPS950 (D11-725hp @ 2,500rpm)

• (2) IPS 2 drive
• (2) Volvo® P5 propeller set
• Volvo® IPS autopilot with reactor
• Volvo® DPS (dynamic positioning system)
  – (2) Volvo® glass cockpit 19″ display
• (1) Volvo® 7″ engine management display
• (1) Volvo® engine controls
• Joystick docking
• Joystick control
• Joystick docking assist
• Slow speed
• Cruise control
• Single lever
• Humphree trim with active ride
• Extra alternator package – lithium compatible (12v)

• Owner’s manual
• (8) Chafe matts & woolies
• (8) 5/8″ Mooring ropes (20′)
• (8) Fenders with fender lines
• Engine & vessel spares kit
• Safety equipment (as per USCG req.)
